Array Acoustic Baffle - SoundBox
M30 / 50 / 100
Array Acoustic Baffle
Suitable for gymnasiums, public places, exhibition venues, sports spaces, performing arts spaces, bars/restaurants, and equipment rooms.
- Model：
M30 / 50 / 100
- Dosage：
Reference Acoustic Design
- Fire Resistance：
Class A
- Environmental Friendly：
The formaldehyde release is ≤0.4mg/L, which meets the "Formaldehyde Release in Interior Decoration Materials and Artificial Board Cotton Products" (GB18580-2001). The 24-hour release of glass fiber particles is 1.7mg/m³. The environmental protection is better than the national E1 standard, and the standard limit is 0.15mg/m³.
- Scope of Application：
Athletic facilities, public venues, convention centers, sports spaces, performance venues, bars and restaurants, equipment rooms
- Fire-Retardant Acoustic Panels：
- Unit weight：
M30 - 3.1kg/m² M50 - 5.5kg/m² M100 - 11.5kg/m²
- Common Specifications：
W600/800/1200 * L1200/1800/2400 * D30/50/100mm
- Installation Method：
Horizontal, Vertical
- Structure：
Die-molded alloy frame housing, featuring custom-engineered wide-frequency composite acoustic foam, adhesive-free thermally bonded sealed acoustic felt, and a surface layer of fire-retardant waterproof acoustic fabric.
- Sound Absorption Coefficient：
Array Acoustic Baffle
